RAIN BOX
Furnace Humidifier
3DDD The Third Dimension Inc. have designed a new innovative furnace humidifier to replace the competitions drum wicking system. This new design will make it easier for the owner to operate and clean with no consumables to replace like filters and wicking drums. Other benefits of this product will support SMART technology using Cell, Wi-Fi to control and monitor your system making it compatible with Hey Google and Alexa.
The most benefit a homeowner will see is that this new furnace humidifier only needs to operate using 5V 2amps power similar to your cell phone instead of traditional systems that need to be plugged into 120VAC power.
HOW IT WORKS
Using only a pump and the power of the rain shower in a box!
EASY SETUP SELF CONTAINED
SEAMLESS CONNECTIVITY USING A SMART PLUG TO CONTROL ITS OPERATIONS
Experience hassle-free setup and connectivity. Simply connect your 5V 2amp power adapter to a smart switch and the humidifier is controlled using an app on your cell or over a computer thru a Wifi Connection to your home.
SMART
FUNCTIONALITY
USB Water Pump
5V 2amp current draw
ENERGY EFFICIENCY
SMART SENORS
Smart Senor
Water Leak Detection
and Auto On/Off
QUALITY PARTS
Nylon Water Float Valve
Fail Safe Water Shut off
in case of failure or power loss
Software
Confirguration
There are simple 'If Than' rules that need to added to your software installation on your device in order to properly operate your rainbox furnace humidifier.
Once you follow the manufactures steps on your chosen device to operate your humidifier with, either a home dedicated tablet or cell phone, you will have to provide identifiable names to the Accessories you add.
Smart Power plug 1 - rename to be 'Pump Power Plug '
Smart Power plug 2 - remame to be 'Valve Power Plug'
USB Hub Controller - 'Rainbox Hub'
Water Leak Senor - 'Rainbox Water Leak Sensor'
Humidify/Temperature Sensor - 'Rainbox Temp/Humidify Sensor'
Rule 1 (Automation): If Humidity drops below 34% Then Pump Power Plug turns 'On'
Rule 2 (Automation): If Humidify is above 39% Then Pump Power Plug turns 'Off'
Rule 3 (Automation): If Pump Power Plug is switched 'On' Then 20 min later turn pump power 'Off'
Rule 4 (Automation): If Rainbox Leak Sensor is detected then Valve Power Plug turns 'Off'
To note: When the Rainbox Leak Sensor is tripped, you should investigate as soon as possible the reason why it tripped. Your humidifier water valve is now in 'Off preventing any flooding due to overflow of the reservoir on your humidifier. It may require cleaning or service. Once the fault has been cleared and your humidifier is ready for operation once again, press the button on the side of the Pump Power Plug to be switched 'on' in order to open the valve to allow the humidifier reservoir to fill properly.
Product Benifits
No Consumables
no moving parts, filters or drums to replace. Only routine cleaning required
Its a SMART Device
you can control it with
an app on your phone phone or compouter.
Energy Efficient
5V - 2amp power supply only needed to operate the device
100% Canadian Made! Made in Edmonton
Patent Pending
Clear See Thru Case
Designed to easily identify problems like calcium giving you a visual ability to assess maintenance
Reversable design
The case can be configured to be both a left or right orientations and easly comes apart like a puzzle for easy cleaning
Reliability
The float valve is made from durable Nylon materials that will not break down due to exposure to calcium buildup
Flood prevention
A Solenoid Valve is supplied with this product to automatically shut off the water supply to the humidifier when a fault is detected or power loss to the system
